Demonstration wet gas meter

Demonstration wet gas meter

Creative Commons LicenseThis image is released under a CC BY-NC-SA 4.0 Licence

License this image for commercial use at Science and Society Picture Library

License

Science Museum Group
© The Board of Trustees of the Science Museum

Demonstration wet gas meter, showing internal construction.

Details

Category:
Gas Industry
Object Number:
1862-32
Measurements:
overall: 430 mm x 300 mm x 350 mm,
type:
gas meter, wet, sectioned
credit:
Bischoff, Brown and Co.
