Diasonograph NE42005 ultrasound scanner comprising scanner stand and electronics/display module

Made:
1982 in Edinburgh

Diasonograph NE42005 ultrasound scanner comprising scanner stand and electronics/display module, by Fischer Ultrasound, Edinburgh, 1982

Details

Category:
Clinical Diagnosis
Object Number:
1986-1071
Materials:
steel and glass
Measurements:
scanner: height 2060 mm
scanner: depth 1620 mm
scanner: width 1210 mm
monitor: height 1270 mm
monitor: depth 990 mm
monitor: width 593 mm
type:
ultrasound scanners
credit:
Hillingdon Hospital. X Ray Dept.

Parts

Display monitor for diasonograph NE42005 ultrasound scanner

Display monitor for diasonograph NE42005 ultrasound scanner

Display monitor for diasonograph NE42005 ultrasound scanner, by Fischer Ultrasound, Edinburgh, 1982

Measurements:
overall: 1310 mm x 1060 mm x 760 mm,
Object Number:
1986-1071 Pt1
type:
monitor
Image ©
The Board of Trustees of the Science Museum
Frame

Frame

Frame

Measurements:
overall: 2054 mm x 1700 mm x 1224 mm,
Object Number:
1986-1071 Pt2
type:
frame - furnishing
Image ©
The Board of Trustees of the Science Museum
