German REV1 Gunsight

German REV1 gunsight

Creative Commons LicenseThis image is released under a CC BY-NC-SA 4.0 Licence

License this image for commercial use at Science and Society Picture Library

License

German REV1 gunsight
Science Museum Group
© The Board of Trustees of the Science Museum

German REV1 gunsight. As used in ME109 and other German fighters. On stand. No inscription - a trait of German military equipment.

Details

Category:
Farnborough
Object Number:
1993-1833
Measurements:
height 405 mm
diameter 310 mm
weight 2 kg
type:
sight - firearm component
