Ring and Bead sight

Ring and Bead sight

Creative Commons LicenseThis image is released under a CC BY-NC-SA 4.0 Licence

License this image for commercial use at Science and Society Picture Library

License

Ring and Bead sight
Science Museum Group
© The Board of Trustees of the Science Museum

Ring and Bead sight, the first effective sight used in the 1914-18 war, and an Aldis collimated telescope sight mounted on common stand. Used in SE5 aircraft.

Details

Category:
Farnborough
Object Number:
1993-2083
Materials:
brass & steel & wood (base) & glass
Measurements:
length 645 mm
width 250 mm
height 150 mm
weight 3 kg
type:
telescope - sighting and telescope - refracting
