37 assorted steam valve internal patterns for locomotive components ex Sheffield Forgemasters

Details

Category:
Locomotives and Rolling Stock Components
Object Number:
1993-7282
Measurements:
box: 115 mm x 285 mm x 425 mm,
type:
pattern
credit:
Sheffield Development Corporation
