1 cylinder end cover pattern for locomotive components

1 cylinder end cover pattern for locomotive components

Creative Commons LicenseThis image is released under a CC BY-NC-SA 4.0 Licence

License this image for commercial use at Science and Society Picture Library

License

Science Museum Group
© The Board of Trustees of the Science Museum

1 cylinder end cover pattern for locomotive components ex Sheffield Forgemasters

Details

Category:
Locomotives and Rolling Stock Components
Object Number:
1993-7290
Measurements:
overall: 80 mm x 460 mm
type:
pattern
credit:
Sheffield Development Corporation
