Two specimens of the London to Birmingham co-axial cable laid by the General Post Office, British, 1935-1936. The first long distance co-axial cable in Britain.

Two specimens of the London to Birmingham co-axial cable laid by the General Post Office, British, 1935-1936. The first long distance co-axial cable in Britain.

This is a sample of the cable laid between London and Birmingham in 1935-36. It was the first long-distance co-axial cable to be laid in Britain, and the 130 mile system provided 40 channels for telephone traffic. Coaxial cables have an inner conductor surrounded by an insulating layer and enclosed in a shield layer, plus an outer insulation jacket. This structure helps to prevent electromagnetic interference.

Details

Category:
Telecommunications
Object Number:
1970-355
Materials:
metal (unknown) and copper (alloy)
Measurements:
overall (small specimen): 34 mm x 45 mm diameter, .207 kg
overall (large specimen): 235 mm x 45 mm diameter, .803 kg
type:
cable
credit:
Donated by STC plc

Parts

Specimen of London-Birmingham co-axial cable, 1935-1936

Specimen of London-Birmingham co-axial cable, 1935-1936

Larger specimen of the London to Birmingham co-axial cable laid by the British Post Office in 1935-36, the first long distance co-axial cable in Britain.

More

This is a sample of the cable laid between London and Birmingham in 1935-36. It was the first long-distance co-axial cable to be laid in Britain, and the 130 mile system provided 40 channels for telephone traffic. Coaxial cables have an inner conductor surrounded by an insulating layer and enclosed in a shield layer, plus an outer insulation jacket. This structure helps to prevent electromagnetic interference.

Measurements:
overall: 235 mm x 45 mm diameter, 0.803 kg
Materials:
copper (alloy) and metal (unknown)
Object Number:
1970-355/1
type:
cable - object genre
Specimen of London-Birmingham co-axial cable, 1935-1936

Specimen of London-Birmingham co-axial cable, 1935-1936

Smaller specimen of the London to Birmingham co-axial cable laid by the British Post Office in 1935-36, the first long distance co-axial cable in Britain.

Measurements:
overall: 34 mm x 45 mm diameter, 0.207 kg
Materials:
copper (alloy) and metal (unknown)
Object Number:
1970-355/2
