Coil about 240 turns No. 28 S.W.G. aluminium wire to suit gap but with tripod broken away
- maker:
- Oliver Joseph Lodge
This image is released under a CC BY-NC-SA 4.0
Licence
License this image for commercial use at Science and Society Picture Library
License
Science Museum Group
© The Board of Trustees of the Science Museum
Coil about 240 turns No. 28 S.W.G. aluminium wire to suit gap but with tripod broken away, part of Oliver Lodge’s microphone amplifier or relay, 1898 (British patent 9712 of 1898) ), a precursor of the moving-coil loudspeaker
Details
- Category:
- Radio Communication
- Object Number:
- 1926-714
- Materials:
- aluminium (metal)
- Measurements:
-
overall: 19 mm 95 mm, .024 kg
- type:
- coil
- credit:
- Sir Oliver Lodge.
