Model (scale 1:4), of double blast steam powered threshing machine, with removable panels

Model (scale 1:4), of double blast steam powered threshing machine, with two removable mahogany side panels, to reveal the inner workings, by Mr Hailstone, England, 1860-1880. The model represents a double blast steam powered threshing machine, the type of which were made between 1850 and 1860 by Wallis, Haslam & Steevens, Hampshire, England, and Clayton and Shuttleworth, Lincoln, Suffolk, England.

Model (scale 1:4). This model represents a double-blast threshing machine made in 1860 by Wallis, Haslam and Steevens. The machine was designed to be powered by a portable steam engine or, as the 19th century progressed, more often by an agricultural steam traction engine. Unlike earlier barn based-threshing machinery these threshers were mobile and were usually moved from job to job, either by horse power or, later, by the traction engine itself.

Details

Category:
Agricultural Engineering
Object Number:
1900-32
Measurements:
overall: 24.8031 x 25.9843 x 42.5197 in.; 630 x 660 x 1080 mm
type:
farming, machines and threshing engines
credit:
W. G. Hailstone

Parts

Model (scale 1:4), of double blast steam powered threshing machine, with two removable mahogany side panels, to reveal the inner workings

Model (scale 1:4), of double blast steam powered threshing machine, with two removable mahogany side panels, to reveal the inner workings

Model (scale 1:4), of double blast steam powered threshing machine, by Mr Hailstone, England, 1860-1880

More

Model (scale 1:4). This model represents a double-blast threshing machine made in 1860 by Wallis, Haslam and Steevens. The machine was designed to be powered by a portable steam engine or, as the 19th century progressed, more often by an agricultural steam traction engine. Unlike earlier barn based-threshing machinery these threshers were mobile and were usually moved from job to job, either by horse power or, later, by the traction engine itself.

The double-blast refers to the provision of two fans employed during the winnowing stage. The vendor, Mr. W. G. Hailstone of Basingstoke, informed the Museum that his late father had made the model 'for exhibition'. Portions of the model have been 'cut-away', either by the maker, or later by the Museum, to show the inner workings of the threshing drum. We do not know if the late Mr. Hailstone Senior had been a craftsman employed at the firm but the level of detail suggests that the maker was very familiar with the full-size item, and the quality of finish would imply a skilled hand. The vendor goes on to note that the nuts, bolts and screws used in its construction are hand-made.

Measurements:
overall: 24.8031 x 25.9843 x 42.5197 in.; 630 x 660 x 1080 mm
Object Number:
1900-32/1
type:
farming , machines and threshing engines
Two removable mahogany side panels

Two removable mahogany side panels

Two removable mahogany side panels, from model (scale 1:4), of double blast steam powered threshing machine, by Mr Hailstone, England, 1860-1880

Materials:
mahogany (wood)
Object Number:
1900-32/2
type:
side panels
