Complete model of Admiralty pattern machine steam boiler

Sectional model, scale 1:12, of an Admiralty pattern machine steam boiler of 2000 hp fitted with forced draught arrangements, one of a set of six single-ended return 'Scotch' boilers fitted in the HMS 'Trafalgar' showing the boilers setting within the vessel (c.1889), unsigned, British, 1889

Details

Category:
Marine Engines
Object Number:
1889-80
Materials:
wood (unidentified), brass (copper, zinc alloy), paint and complete
Measurements:
overall: 660 mm x 1100 mm x 455 mm,
type:
model - representation and steam boiler
credit:
Board of Admiralty
