Jacquard machine of one hundred needles and harness for M4040

Made:
1912 in Oldham
maker:
Platt Brothers and Company Limited
Jacquard machine of one hundred needles and harness for M4040

Creative Commons LicenseThis image is released under a CC BY-NC-SA 4.0 Licence

License this image for commercial use at Science and Society Picture Library

License

Science Museum Group
© The Board of Trustees of the Science Museum

Jacquard machine of one hundred needles and harness for M4040, dated 1912, which combines with inv. no. 1912-320 to form a Jacquard loom.

Details

Category:
Textiles Machinery
Object Number:
1912-321
Materials:
cast iron and steel
Measurements:
overall: 735 mm x 410 mm x 580 mm,
type:
jacquard mechanism
credit:
Platt Bros. and Co.
