Britannia screwcutting lathe and accessories

Britannia screwcutting lathe and accessories

Details

Category:
Hand and Machine Tools
Object Number:
1973-237
type:
lathes
credit:
Smith, A.P.

Parts

Britannia screwcutting lathe

Britannia screwcutting lathe

Britannia screwcutting lathe with five change speed gears fitted

Measurements:
overall: 1165 mm x 1160 mm x 535 mm,
Object Number:
1973-237/1
type:
lathes
Image ©
The Board of Trustees of the Science Museum
Britannia screwcutting lathe and overhead gear consisting of two standards

Britannia screwcutting lathe and overhead gear consisting of two standards

Britannia screwcutting lathe and overhead gear consisting of two standards, pulleys on shaft and stay and crane

Measurements:
overall: 1760 mm x 900 mm x 280 mm,
Object Number:
1973-237/2
type:
lathes
Image ©
The Board of Trustees of the Science Museum
Britannia screwcutting lathe accessories of two weights

Britannia screwcutting lathe accessories of two weights

Britannia screwcutting lathe accessories of two weights, belting, two detachable handles and one small lever

Object Number:
1973-237/3
type:
lathes
Image ©
The Board of Trustees of the Science Museum
Cross centre for use with softwood

Cross centre for use with softwood

Cross centre for use with softwood;a plain centre and a square centre.

Object Number:
1973-237/4
type:
cross centre
Image ©
The Board of Trustees of the Science Museum
A set of change wheels

A set of change wheels

A set of change wheels,teeth numbers being- 21, 23, 24, 25, 30, two of 40, and 45 to 85 in 5 teeth steps and a 100 tooth wheel all mounted on a stand.

Object Number:
1973-237/7
type:
wheel
Image ©
The Board of Trustees of the Science Museum
Three pinions from the tumbler reverse.

Three pinions from the tumbler reverse.

Three pinions from the tumbler reverse.

Measurements:
overall: 40 mm 35 mm,
Object Number:
1973-237/8
type:
pinion
Image ©
The Board of Trustees of the Science Museum
A drill and eccentric cutting spindle.

A drill and eccentric cutting spindle.

A drill and eccentric cutting spindle.

Object Number:
1973-237/9
type:
drill - tool
Image ©
The Board of Trustees of the Science Museum
Countershaft, wall bracket

Countershaft, wall bracket

Countershaft, wall bracket, fast and loose pulley wheels and a belt striker with a cone pulley that may be for the above.

Measurements:
overall: 230 mm x 145 mm x 300 mm,
Object Number:
1973-237/10
type:
countershaft
Image ©
The Board of Trustees of the Science Museum
objects that may or may not belong to the Britannia lathe;a broken boss with a square hole

objects that may or may not belong to the Britannia lathe;a broken boss with a square hole

objects that may or may not belong to the Britannia lathe;a broken boss with a square hole,a mandrel for a common headstock, hardwood workpiece,brass socket,a keeper,two nuts a bolt, nut and washer.

Object Number:
1973-237/11
type:
component
Image ©
The Board of Trustees of the Science Museum
