Countershaft with 4 step cone pulley & fast & loose wheels
This image is released under a CC BY-NC-SA 4.0
Licence
License this image for commercial use at Science and Society Picture Library
License
Science Museum Group
© The Board of Trustees of the Science Museum
Countershaft with 4 step cone pulley & fast & loose wheels, 2 bearings & hangers complete with striking bar and fork pieces; countershaft with fast & loose wheels and a large pulley & 2 bracket bearings; 3 light iron pulleys; 5 oil bath plummer blocks (lack some bolts & nuts) ; 1 light self-aligning shaft hanger; 1 3 step iron pulley
Details
- Category:
- Hand and Machine Tools
- Object Number:
- 1975-331/5
- Measurements:
-
overall: 400 mm x 1830 mm x 1360 mm,
- type:
- countershaft
- credit:
- Brinton, C.C.
