A countershaft with 2 plummer blocks and 4 pulleys; a counter shaft with 4-step pulleys
This image is released under a CC BY-NC-SA 4.0
Licence
License this image for commercial use at Science and Society Picture Library
License
Science Museum Group
© The Board of Trustees of the Science Museum
A countershaft with 2 plummer blocks and 4 pulleys; a counter shaft with 4-step pulleys, fast & loose pulleys & another pulley, 2 bearings & hangers, 2 composite metal pulleys & 3 wooden pulleys
Details
- Category:
- Hand and Machine Tools
- Object Number:
- 1975-331/7
- Measurements:
-
overall: 355 mm x 119 mm x 966 mm,
- type:
- countershaft
- credit:
- Brinton, C.C.
