Machined workpiece
- Made:
- 1983
This image is released under a CC BY-NC-SA 4.0
Licence
License this image for commercial use at Science and Society Picture Library
License
Science Museum Group
© The Board of Trustees of the Science Museum
A machined workpiece being a suitable sample for demonstrating the operation of the Mitutoyo coordinate measuring machine being a machined aluminium head of a 3 cylinder combustion engine.
Details
- Category:
- Industrial Metrology
- Object Number:
- 1983-1178 Pt7
- Materials:
- steel (metal)
- Measurements:
-
5.5118 x 10.2362 x 6.2992 in.; 140 x 260 x 160 mm
