Model of Vibro-concrete Pile Driving Plant

maker:
London Underground
Model of Vibro-concrete Pile Driving Plant

Creative Commons LicenseThis image is released under a CC BY-NC-SA 4.0 Licence

License this image for commercial use at Science and Society Picture Library

License

Science Museum Group
© The Board of Trustees of the Science Museum

Model of vibro-concrete pile driving plant, scale 1:12

Details

Category:
Building Construction
Object Number:
1928-1090
Measurements:
Boxed components: 340 mm x 630 mm x 480 mm,
Crane arm: 330 mm x 160 mm x 1370 mm,
type:
model
credit:
British Steel Piling Co. Ltd.
