Triangular Support Unit for Object Generator

PART OF:
Components of EROS IV optical transfer function measurement system for lens testing
Made:
1963-1969 in Watford
maker:
R and J Beck
Triangular Support Unit for Object Generator

Creative Commons LicenseThis image is released under a CC BY-NC-SA 4.0 Licence

License this image for commercial use at Science and Society Picture Library

License

Science Museum Group
© The Board of Trustees of the Science Museum

Triangular support unit for object generator, with three pads to go under the feet, EROS IV optical transfer function measuring system for lens testing, made by R & J Beck Ltd. in about 1966

Details

Category:
Optics
Object Number:
1993-1461 Pt12
Measurements:
overall: 190 mm x 400 mm x 340 mm,
type:
support
credit:
Ealing Electro-Optics Plc
