Back Casing with Stop Valve and Throttle
Back casing, with stop valve and throttle (hand lever bent), nuts on all studs, half-bearing and half labyrinth for top end of spindle and half-labyrinth for bottom end of spindle
250 H.P. steam turbine with vertical shaft. Made by W.H. Allen and Sons
250 H.P. steam turbine with vertical shaft. Made by W.H. Allen and Sons, Bedford, about 1937. Height: 4ft, width 3ft 6". Weight approx. 1 ton
Details
Parts
Half-Bearing for Bottom End of Spindle
Half-bearing for bottom-end of spindle to fit back casing
Rotor with Packings and Blade Rings
Rotor with packings above and below. Blade-rings in place
Front Lower Bearing Housing
Front lower bearing housing with half-bearing and half-labyrinth in place
Front Casing with Half-Diaphragms in Place
Front casing with half-diaphragms in place
Front Cutting Top
Front cutting top
Top Cover to Upper Bearing Housing
Top cover to upper bearing housing
Michell Thrust Bearing
Michell Thrust bearing comprising split ring (2 parts) and 5 pads (should be 6)
Eight Shaped Lagging Blankets
8 shaped lagging blankets
- Object Number:
- 1971-496/9
- type:
- lagging blankets
- Image ©
- The Board of Trustees of the Science Museum
Five Leading Plates in 'Russian Iron'
5 leading plates in 'Russian Iron'
- Materials:
- iron
- Object Number:
- 1971-496/10
- type:
- leading plates
- Image ©
- The Board of Trustees of the Science Museum
Pipes, Handwheel, Bolts, Nuts and Screws
Small pipes, handwheel, bolts, nuts and screws and other small items
