Sectioned example of Joy's Assistant Cylinder for Slide Valves

Made:
1889
Sectioned example of Joy's Assistant Cylinder for Slide Valves

Creative Commons LicenseThis image is released under a CC BY-NC-SA 4.0 Licence

License this image for commercial use at Science and Society Picture Library

License

Science Museum Group
© The Board of Trustees of the Science Museum

Sectioned example of Joy's Assistant Cylinder for Slide Valves, 1889 (Ex.1897-56 Pr.) ( See diagram 1927-2035)

Details

Category:
Motive Power
Object Number:
1900-215
Measurements:
overall: 530 mm x 310 mm x 240 mm,
type:
example
credit:
Joy, D. (EC)
