Delvac Mechanical Lubricator

Delvac Mechanical Lubricator

Creative Commons LicenseThis image is released under a CC BY-NC-SA 4.0 Licence

License this image for commercial use at Science and Society Picture Library

License

Science Museum Group
© The Board of Trustees of the Science Museum

Delvac Mechanical Lubricator, two-feed model; part of oil container and one complete pump unit sectioned, no.15134

Details

Category:
Motive Power
Object Number:
1938-110
Measurements:
overall: 360 mm x 300 mm x 120 mm,
type:
lubricator
credit:
Vacuum Oil Co. Ltd.
