Sectioned model, scale 5/16" = 1 ft., of a Single Flow Yarrow Boiler, type SF 3, for use on land (with special packing case)

Details

Category:
Motive Power
Object Number:
1955-56
Measurements:
overall (contained in crate): 960 mm x 855 mm x 680 mm,
overall (model): 850 mm x 780 mm x 675 mm,
type:
model
credit:
Yarrow and Co. Ltd.
