Set of Orifice Fittings for type T/PD Steam Flow Recorder

Made:
England
Set of Orifice Fittings for type T/PD Steam Flow Recorder

Creative Commons LicenseThis image is released under a CC BY-NC-SA 4.0 Licence

License this image for commercial use at Science and Society Picture Library

License

Science Museum Group
© The Board of Trustees of the Science Museum

Set of Orifice Fittings for type T/PD Steam Flow Recorder

Details

Category:
Motive Power
Object Number:
1935-147
Measurements:
overall: 525 mm x 850 mm x 428 mm,
type:
fittings
credit:
Kindly donated by ABB Limited
