C.H. Armstrong patent 1925 Thermostatic Steam Trap for 5/8" diam. pipe

C.H. Armstrong patent 1925 Thermostatic Steam Trap for 5/8" diam. pipe

Creative Commons LicenseThis image is released under a CC BY-NC-SA 4.0 Licence

License this image for commercial use at Science and Society Picture Library

License

Science Museum Group
© The Board of Trustees of the Science Museum

C.H. Armstrong patent 1925 Thermostatic Steam Trap for 5/8" diam. pipe

Details

Category:
Motive Power
Object Number:
1928-201
Materials:
metal (unknown)
Measurements:
overall: 984 mm x 245 mm x 245 mm,
type:
trap
credit:
James Gordon and Co. Ltd.
