4 coils of cotton driving rope

PART OF:
Mill Engine by Burnley Ironworks Company
4 coils of cotton driving rope

Creative Commons LicenseThis image is released under a CC BY-NC-SA 4.0 Licence

License this image for commercial use at Science and Society Picture Library

License

Science Museum Group
© The Board of Trustees of the Science Museum

4 coils of cotton driving rope

Details

Category:
Motive Power
Object Number:
1971-78 Pt20
Measurements:
Coil 2: 430 mm x 480 mm x 530 mm,
Coil 3: 440 mm x 540 mm x 540 mm,
Coil 4: 440 mm x 580 mm x 540 mm,
Coil 1: 485 mm x 520 mm x 590 mm,
type:
coil
credit:
Finsley View Manufacturing Co. Ltd.
