A quantity of bolts and nuts and chain

A quantity of bolts and nuts and chain

Creative Commons LicenseThis image is released under a CC BY-NC-SA 4.0 Licence

License this image for commercial use at Science and Society Picture Library

License

Science Museum Group
© The Board of Trustees of the Science Museum

A quantity of bolts and nuts and chain associated with items /2 to /6. Bolts and nuts mostly modern; for use of chains, see photoes of engine before removal to museum

Details

Category:
Motive Power
Object Number:
1920-124/7
Measurements:
overall 1 OF 2: 270 mm x 380 mm x 250 mm,
type:
bolt, nuts and chain
credit:
Haslam, C.M.
