Screw Jack to raise two tons

Screw Jack to raise two tons

Creative Commons LicenseThis image is released under a CC BY-NC-SA 4.0 Licence

License this image for commercial use at Science and Society Picture Library

License

Science Museum Group
© The Board of Trustees of the Science Museum

Screw Jack to raise two tons

Details

Category:
Lifting & Mechanical Handling
Object Number:
1883-21
Measurements:
overall: 250 mm x 130 mm x 90 mm,
type:
screw jack
credit:
Royal College of Science
