Automatic precision resistance A.C. double bridge type A6 with six decade swiches

Made:
1980-1984 in Leighton Buzzard
Automatic precision resistance A.C. double bridge type A6 with six decade swiches

Creative Commons LicenseThis image is released under a CC BY-NC-SA 4.0 Licence

License this image for commercial use at Science and Society Picture Library

License

Science Museum Group
© The Board of Trustees of the Science Museum

Automatic precision resistance A.C. double bridge type A6 with six decade swiches, made by Automatic Systems Laboratories [ASL], Leighton Buzzard, Beds., c.1980.

Details

Category:
Electricity and Magnetism
Object Number:
2000-1073
Materials:
mixed materials and metals
Measurements:
: 710 x 500 x 490 mm
Resistance bridge: 730 mm x 500 mm x 460 mm,
Circuit board: 25 mm x 305 mm x 155 mm,
Connectors: 55 mm x 340 mm x 230 mm,
: mm
type:
resistance bridge
credit:
MetaWave Video Systems Ltd.
