Methane counter from Nimrod

Made:
1964-1978 in Didcot
maker:
STFC Rutherford Appleton Laboratory
Methane counter from Nimrod

Creative Commons LicenseThis image is released under a CC BY-NC-SA 4.0 Licence

License this image for commercial use at Science and Society Picture Library

License

Science Museum Group
© The Board of Trustees of the Science Museum

Methane counter from Nimrod

Details

Category:
Nuclear Physics
Object Number:
1980-234
Measurements:
overall: 740 mm x 740 mm x 310 mm,
type:
detectors
credit:
Rutherford Appleton Laboratory
