Model illustrating McAdam's method of road construction

Model illustrating McAdam's method of road construction

Creative Commons LicenseThis image is released under a CC BY-NC-SA 4.0 Licence

License this image for commercial use at Science and Society Picture Library

License

Science Museum Group
© The Board of Trustees of the Science Museum

Sectional model illustrating McAdam's method of road construction (in glass fronted case)

Details

Category:
Civil Engineering
Object Number:
1937-286
Measurements:
overall: 435 mm x 345 mm x 80 mm,
type:
model
credit:
Transport Research Laboratories Limited; Road Research Laboratory
