Half section of a Weston type clutch for a 1" shaft, as improved by Prof Hele-Shaw in 1901.
Details
- Category:
- Mechanical Power Transmission
- Object Number:
- 1907-22
- Measurements:
-
Two metal rods: 140 mm x 60 mm x 60 mm,
Clutch: 100 mm x 280 mm x 230 mm, 11 kg
- type:
- drive clutch
- credit:
- British Hele-Shaw Patent Clutch Co.
