Snyer's elastic clutch for 1 1/2" shaft patented in 1887 with slot actuating gear, patented in 1892; made in 1908.
Details
- Category:
- Mechanical Power Transmission
- Object Number:
- 1908-23
- Materials:
- steel
- Measurements:
-
overall: 830 mm x 910 mm x 470 mm,
- type:
- driving clutch
- credit:
- Cowlishaw, Walker and Co.
