Timken tapered roller bearing

Made:
1910 in Ohio and Canton
Timken tapered roller bearing

Creative Commons LicenseThis image is released under a CC BY-NC-SA 4.0 Licence

License this image for commercial use at Science and Society Picture Library

License

Science Museum Group
© The Board of Trustees of the Science Museum

Timken tapered roller bearing, short series, medium type no.339, 35mm diameter

Details

Category:
Mechanical Power Transmission
Object Number:
1910-27
Materials:
steel
Measurements:
overall:
type:
roller bearing
credit:
Electric and Ordnance Accessories Co.
