Hand operated double ratchet driving gear for obtaining rotative from reciprocating motion
- Made:
- circa 1908 in London
- maker:
- Zerah Colburn
This image is released under a CC BY-NC-SA 4.0
Licence
License this image for commercial use at Science and Society Picture Library
License
Science Museum Group
© The Board of Trustees of the Science Museum
Hand operated double ratchet driving gear for obtaining rotative from reciprocating motion, on stand
Details
- Category:
- Mechanical Power Transmission
- Object Number:
- 1911-134
- Materials:
- steel
- Measurements:
-
overall: 320 mm x 225 mm x 590 mm,
overall (estimate): 15.748 x 19.685 x 7.874 in.; 400 x 500 x 200 mm
- type:
- driving gear
- credit:
- Coleman, E.W. (London)
