F.J. Worm gear (6/23 gear ratio working at 6" centre distance)
Details
- Category:
- Mechanical Power Transmission
- Object Number:
- 1920-10
- Materials:
- phosphor bronze and steel
- Measurements:
-
overall: 160 mm x 410 mm x 377 mm,
- credit:
- Brown, D. (David) and Sons (Huddersfield)
