Victaulic steel alloy joint 2" x 2 5/8" 300 lbs ty

Victaulic steel alloy joint 2" x 2 5/8" 300 lbs ty

Creative Commons LicenseThis image is released under a CC BY-NC-SA 4.0 Licence

License this image for commercial use at Science and Society Picture Library

License

Science Museum Group
© The Board of Trustees of the Science Museum

Victaulic steel alloy joint 2" x 2 5/8" 300 lbs type water 5.20.08 (.... for shouldered type Victaulic pipes)

Details

Category:
Mechanical Power Transmission
Object Number:
1928-1018
Measurements:
overall: 50 mm x 140 mm x 130 mm,
type:
joint
credit:
Victaulic Co. Ltd.
