"Thrapston" industrial VEEFLAT Drive exhibition set, consisting of pulleys and "V" ropes, showing principle of "Thrapston" VEEFLAT Drive.
Details
- Category:
- Mechanical Power Transmission
- Object Number:
- 1932-274
- Measurements:
-
overall: 550 mm x 820 mm x 395 mm,
: 21.6535 x 35.4331 x 5.9055 in.; 550 x 900 x 150 mm
- type:
- belt drive
- credit:
- Smith and Grace, Screw Boss Pulley Co.
