Sectioned example of worm gear teeth
This image is released under a CC BY-NC-SA 4.0
Licence
License this image for commercial use at Science and Society Picture Library
License
Science Museum Group
© The Board of Trustees of the Science Museum
Sectioned example of worm gear teeth in mesh in wooden box
Details
- Category:
- Mechanical Power Transmission
- Object Number:
- 1969-354
- Measurements:
-
overall: 55 mm x 120 mm x 83 mm,
- type:
- gear teeth
- credit:
- Renold Ltd.
