Specimen of Seymour Resilient Steel Gear
- Made:
- 1921 in Darlington
This image is released under a CC BY-NC-SA 4.0
Licence
License this image for commercial use at Science and Society Picture Library
License
Science Museum Group
© The Board of Trustees of the Science Museum
Specimen of Seymour resilient steel gear, showing building up of Seymour's laminated pinion:- Laminae after welding, turning and boring, cone and ring removed.
Details
- Category:
- Mechanical Power Transmission
- Object Number:
- 1921-584
- Materials:
- steel
- Measurements:
-
overall: 80 mm x 138 mm x 138 mm,
- type:
- gear wheel
- credit:
- T. Summerson and Sons Ltd.
