Variable speed belt driven gearbox

Made:
1910-1922 in Columbus
Variable speed belt driven gearbox

Creative Commons LicenseThis image is released under a CC BY-NC-SA 4.0 Licence

License this image for commercial use at Science and Society Picture Library

License

Science Museum Group
© The Board of Trustees of the Science Museum

Variable speed belt driven gearbox, made by Churchill & Co. (agent or licensee?), made or dsigned by Reeves Pulley Company

Details

Category:
Mechanical Power Transmission
Object Number:
1922-292
Measurements:
overall: 320 mm x 1190 mm x 815 mm,
type:
varible speed gear
credit:
Churchill, C. (Charles) and Co.
