Citroen double herringbone spur wheel

Made:
1922 in Paris

Citroen double herringbone spur wheel (65 teeth) with pinion (13 teeth)

Details

Category:
Mechanical Power Transmission
Object Number:
1922-549
Materials:
forged steel and cast steel
Measurements:
overall: 350 mm x 350 mm x 220 mm,
type:
gear wheels
credit:
Citroen Gear Co. Ltd.
