Model sheet mill driving gear and starter mechanism
Model sheet mill driving gear and starter mechanism
model, scale 1:8
- Made:
- 1923-1924 in West Drayton
- maker:
- Power Plant Company
model, scale 1:8, of combined driving, starting and roll-turning Gear for cold Roll Sheet Mills
Details
- Category:
- Mechanical Power Transmission
- Object Number:
- 1924-730
- type:
- gear boxes and models
- credit:
- Power Plant Co. Ltd.
Parts
Model of electric motor
Model of electric motor
- Measurements:
-
overall: 290 mm x 295 mm x 285 mm,
- Object Number:
- 1924-730/2
- type:
- model
- Image ©
- The Board of Trustees of the Science Museum
Model of Turning rolls for cold roll sheet mills
Model of Turning rolls for cold roll sheet mills
- Measurements:
-
overall: 370 mm x 400 mm x 285 mm,
- Object Number:
- 1924-730/3
- type:
- model
- Image ©
- The Board of Trustees of the Science Museum
Model of drive connector of holding down bolts
Model of drive connector of holding down bolts
- Measurements:
-
overall (polybag): 40 mm x 320 mm x 230 mm,
- Object Number:
- 1924-730/4
- type:
- model
- Image ©
- The Board of Trustees of the Science Museum
