Length of solid woven cotton belt double substance, joined with alligator fastener and rawhide pin

Made:
1926 in London
Length of solid woven cotton belt double substance, joined with alligator fastener and rawhide pin

Creative Commons LicenseThis image is released under a CC BY-NC-SA 4.0 Licence

License this image for commercial use at Science and Society Picture Library

License

Science Museum Group
© The Board of Trustees of the Science Museum

Length of solid woven cotton belt double substance marked S.W.C., joined with alligator fastener and rawhide pin, by Geo Angus and Co., London, EC3, England, 1926.

Details

Category:
Mechanical Power Transmission
Object Number:
1926-349
Materials:
cotton, steel and rawhide
Measurements:
overall; overall (estimate): 10 mm x 105 mm x 420 mm,
type:
belt drive
credit:
Angus, G. (Geo) and Co. Ltd.
