Hammond organ

Made:: 1937 in Chicago

Hammond Model "E" organ complete with pedal board, bench and amplifier and speaker in wooden casing, Serial No. 8282, 1937.

Details

Category:: Acoustics

Object Number:: 1980-444

type:: organ

credit:: Holland, F.

Cite this page

Rights

We encourage the use and reuse of our collection data.

Data in the title, made, maker and details fields are released under Creative Commons Zero . Descriptions and all other text content are licensed under a Creative Commons Attribution 4.0 licence

Download

Download catalogue entry as json

Download manifest IIIF

Our records are constantly being enhanced and improved, but please note that we cannot guarantee the accuracy of any information shown on this website.

Parts

Console, for Hammond Model 'E' organ, Serial No. 8282

Console, for Hammond Model 'E' organ, Serial No. 8282

Console for Hammond Organ, Model E Serial No. 8282, 1937.

Measurements:: overall (combined with Pt5): 1005 mm x 1473 mm x 1215 mm, 240 kg

Materials:: wood (unidentified) , metal (unknown) , plastic (unidentified) , paper (fibre product) , paper tape and rubber (unidentified)

Object Number:: 1980-444 Pt1

type:: console

Image ©: The Board of Trustees of the Science Museum

Amplifier for Hammond Organ, Model E, Serial No. 8282, 1937

Amplifier for Hammond Organ

Amplifier for Hammond Organ, Model E, Serial No. 8282, 1937

Measurements:: overall: 1000 mm x 750 mm x 400 mm,

Object Number:: 1980-444 Pt2

type:: amplifiers

Loudspeaker for Hammond Model "E" Serial No. 8282, 1937.

Loudspeaker for Hammond Model "E" Serial No. 8282

Loudspeaker for Hammond Model "E" Serial No. 8282, 1937.

Object Number:: 1980-444 Pt3

type:: loudspeaker

Bench, for Hammond Model 'E' organ, Serial No. 8282

Bench, for Hammond Model 'E' organ, Serial No. 8282

Bench for Hammond Model "E" organ Serial No. 8282, 1937.

Measurements:: overall: 605 mm x 1171 mm x 372 mm, 20 kg

Materials:: wood (unidentified) , paint and paper (fibre product)

Object Number:: 1980-444 Pt4

type:: benches

Image ©: The Board of Trustees of the Science Museum

Pedal board, for Hammond Model 'E' organ, Serial No. 8282

Pedal board, for Hammond Model 'E' organ, Serial No. 8282

Pedal board, for Hammond Model 'E' organ, Serial No. 8282

Pedal board for Hammond Model "E" organ Serial No. 8282, 1937.

Measurements:: overall (combined with Pt1): 1005 mm x 1473 mm x 1215 mm, 240 kg

Materials:: wood (unidentified) , rubber (unidentified) , plastic (unidentified) , metal (unknown) and paper tape

Object Number:: 1980-444 Pt5

type:: pedalboard

Image ©: The Board of Trustees of the Science Museum

Painted wooden block from Hammond Model 'E' organ, Serial No. 8282

Painted wooden block from Hammond Model 'E' organ, Serial No. 8282

Painted wooden block from Hammond Model 'E' organ, Serial No. 8282

Rectangular wooden block with two screws on the underside, painted with a cream gloss finish, from the Hammond Model "E" organ Serial No. 8282, 1937.

Measurements:: overall: 30 mm x 235 mm x 136 mm, .531 kg

Materials:: wood (unidentified) and paint

Object Number:: 1980-444 Pt6

type:: electronic organs

Image ©: The Board of Trustees of the Science Museum

Bags of screws and bolts from Hammond Model 'E' organ, Serial No. 8282

Bags of screws and bolts from Hammond Model 'E' organ, Serial No. 8282

Two bag of screws and bolts from the Hammond Model "E" organ Serial No. 8282, 1937.

Measurements:: overall (in larger bag): 16 mm x 250 mm x 150 mm, .176 kg

Materials:: metal (unknown)

Object Number:: 1980-444 Pt7

type:: electronic organs and screw

Image ©: The Board of Trustees of the Science Museum
