2 Links of 2.5" pitch
- Made:
- Coventry
This image is released under a CC BY-NC-SA 4.0
Licence
License this image for commercial use at Science and Society Picture Library
License
Science Museum Group
© The Board of Trustees of the Science Museum
2 Links of 2.5" pitch, 1.5" nominal width roller chain no.6121 made by Renold Ltd, sectioned to show construction
Details
- Category:
- Mechanical Power Transmission
- Object Number:
- 1911-139
- Materials:
- steel
- Measurements:
-
overall: 73 mm x 178 mm x 52 mm,
- type:
- transmission chain
- credit:
- Renold and Coventry Chain Co.; Hans Renold Ltd.
