Small model of Hydraulic Capstan

Small model of Hydraulic Capstan, Brotherhood System, 1907, in wooden case with 2 spanners, 1 key, 3 box spanners, 1 tommy bar

Details

Category:
Mechanical Power Transmission
Object Number:
1934-500
type:
model
credit:
Mrs. E.M. Clayton

Parts

Small model of Hydraulic Capstan

Small model of Hydraulic Capstan

Small model of Hydraulic Capstan, Brotherhood System, 1907

Object Number:
1934-500/1
type:
model
Image ©
The Board of Trustees of the Science Museum
Tools for Model of Hydraulic Capstan

Tools for Model of Hydraulic Capstan

Two spanners, one key, three box spanners, and one tommy bar for small model of Hydraulic Capstan, Brotherhood System, 1907

Object Number:
1934-500/2
type:
tools
Image ©
The Board of Trustees of the Science Museum
