Rack and pinion in gear
- Made:
- circa 1883 in Nottingham
This image is released under a CC BY-NC-SA 4.0
Licence
License this image for commercial use at Science and Society Picture Library
License
Science Museum Group
© The Board of Trustees of the Science Museum
Rack and pinion in gear, the former in slot so as to produce linear motion.
Details
- Category:
- Kinematics
- Object Number:
- 1885-197
- Measurements:
-
overall: 130 mm x 210 mm x 250 mm,
overall (estimate): 5.9055 x 9.8425 x 4.7244 in.; 150 x 250 x 120 mm
- type:
- rack and pinion gear
- credit:
- Blackburn and Attenborough
