Model of bell crank lever used in pumping machiner

Made:
Unknown in unknown
maker:
Unknown
Model of bell crank lever used in pumping machiner

Creative Commons LicenseThis image is released under a CC BY-NC-SA 4.0 Licence

License this image for commercial use at Science and Society Picture Library

License

Science Museum Group
© The Board of Trustees of the Science Museum

Model of bell crank lever used in pumping machinery; made from iron.

Details

Category:
Kinematics
Object Number:
1898-73
Materials:
iron and brass
Measurements:
overall: 216 mm x 338 mm x 89 mm,
overall (estimate): 9.4488 x 12.9921 x 1.378 in.; 240 x 330 x 35 mm
type:
model - bell crank lever
credit:
Museum of Geology, Jermyn Street
