Made-up 3 point support probably for microscope

PART OF:
Lead screw correcting lathe and accessories by Armstrong Whitworth and Co
Made-up 3 point support probably for microscope

Creative Commons LicenseThis image is released under a CC BY-NC-SA 4.0 Licence

License this image for commercial use at Science and Society Picture Library

License

Science Museum Group
© The Board of Trustees of the Science Museum

Made-up 3 point support probably for microscope; fits on tool saddle but does not align correctly

Details

Category:
Industrial Metrology
Object Number:
1983-62/30
Measurements:
overall: 180 mm x 220 mm x 65 mm,
type:
support
