Pump, mounted on tray
Pump, mounted on tray
- Measurements:
-
overall: 460 mm x 305 mm x 820 mm,
- Object Number:
- 1892-123/1
- type:
- pump
- Image ©
- The Board of Trustees of the Science Museum
Worthington Duplex steam pump
In this arrangement of pumping engine, which was originally introduced by H. R. Worthington about 1850, there are two complete double-acting steam cylinders, side by side, directly working similar pumps, but with the strokes so timed that a practically continuous discharge is maintained into the delivery main so that the engine will pump quietly even through long lengths of pipe.
Details
- Category:
- Pumping Machinery
- Object Number:
- 1892-123
- Materials:
- cast iron, bronze (copper, tin alloy), paint and brass (copper, zinc alloy)
- Measurements:
-
overall: 460 mm x 305 mm x 820 mm,
- type:
- steam pump and duplex pump
- credit:
- Worthington Pumping Engine Co.
Parts
4 bib-cocks with union noses
4 bib-cocks with union noses, similar to those on the machine, one union body; two small pump clacks
