Reproduction in section of ancient Roman Plunger Pump with poppet valves

Made:
London
Reproduction in section of ancient Roman Plunger Pump with poppet valves

Creative Commons LicenseThis image is released under a CC BY-NC-SA 4.0 Licence

License this image for commercial use at Science and Society Picture Library

License

Science Museum Group
© The Board of Trustees of the Science Museum

Reproduction in section of ancient Roman Plunger Pump with poppet valves, now at the British Museum

Details

Category:
Pumping Machinery
Object Number:
1914-703
Measurements:
overall: 421 mm x 152 mm x 255 mm,
type:
pump
credit:
Standard Plating & Kupron Works Ltd.
